SWITCH BILGE PUMP W/ALARM SFLO

REF: 194641

  • Voltage：12V / 24V
  • Amps：20A / 10A
  • Wire Gauge Size：16AWG
  • Wire Lead：100mm

FEATURES & BENEFITS

  • For use with seaflo electric field bilge switch，precise operation ensures proper bilge pumping and provides peace of mind.
  • Controls any pump equipped with an automatic float switch.
  • Unique 3-way switch disables piezo alarm while keeping warning LED lit.
  • Three way rocker switch allows alarm to be auto, turned off and man (AUTO-OFF-MAN).
  • Marine switch panel，easy to install



€28.00

Clear
SKU: N/A Category: Brand:

Description

SEAFLO alarm switch panel consists of three-position control buttons and an 85-decibel buzzer. It is a safety reminder control device that integrates visual, auditory and switch control. It can be used with electric field bilge switch, float switch or other places (not limited to the use of cabin water level safety reminders, but can be used in other places that require safety reminders); control any 12V or 24V DC bilge pump with automatic float switch.

Model Number Voltage Current Alarm volume N.W. Wire Gauge Size /length
SFASP1-01 12V DC 20 Amps.Max ≥85DB 0.2KG 16AWG/100mm
SFASP2-01 24V DC 10 Amps.Max ≥85DB 0.2KG 16AWG/100mm

Alarm Switch Panel chi.jpg

Additional information

VOLTS

12V, 24V
