Description
MORE FEATURES
|
– Twist ‘n’ lock action safety handle guards against flooding and waste backflow by locking the waste outlet valve shut. – Reversible pump mounting allows re-assembly for left hand. – operation by installer. – Powerful self-priming, double-acting piston pump. – Strong swirl action for efficient flushing. – Crevice free contours and skirted base for added cleanliness and hygiene. – Contoured handle and conveniently positioned flush control lever for ease of use. – Angled pump housing and long stroke for easier. – pumping.Spring assisted top valve closure for easier priming. |
–Â Automatic vacuum breaker operated by flush control lever for easier bowl emptying.
–Â Constant 38mm (1-1/2″) bore waste path minimises blockages. –Â Aortic joker valve combines full 38mm (1-1/2″) bore with automatic back-flow prevention. –Â Multi-angle discharge elbow for ease of installation. –Â Accessible mounting points for faster installation. –Â All fastenings face front or top for superbly simple servicing without need for special tools. –Â Renewable external seal housing for quick, clean placement of seal and piston rod guide. –Â Positively located gaskets ensure correct re-assembly. –Â Dual function base plug combines winter drain point with easy cleaning access. |
DIMENSIONS
STANDARD PUMP CONFIGURATIONS
| Type | Manually Operated |
| Control Type | Twist ’n’ Lock |
| Size | Compact |
| Diameter | 3/4” Inlet   1-1/2″ Discharge |
| Material | Ceramic bowl, wood seat with baked enamel finish |
| Dimension(L*W*H) | 490 x 445 x 430 mm
(19.29”*17.52”*16.93” ) |
DETAILED COMPOSITION
