MAXWELL WINDLASS RC6 12V 500W

REF: 190011

Suitable for 6mm (1/4″) chain and 12mm (1/2″) 8-plait nylon rope, the RC6 automatic rope/chain anchor winch is Maxwell’s smallest windlass in the vertical RC series and is most commonly used on boats ranging from 4.5-7.5m (15-25′). With more than 12,000 in global circulation, the RC6 has risen to become one of the most popular windlasses in the RC range.

  • The RC6 features Maxwell’s patented Wave Design™ chainwheel. Refer below for more information about this innovative feature.
  • Providing most of the features of the larger RC8, the RC6 has been designed with the smaller, trailer boat market in mind.
  • The in-line, vertical gearbox and motor means quick and easy installation by either the boat yard or the DIY aftermarket customer.
  • An inexpensive, high performance and great looking windlass; the RC6 is built for durability and years of trouble-free use.
  •  The RC6 is a Low-Profile unit meaning there is no optional capstan drum.

4 in stock

975.00

SKU: VT1025X69000 Category: Brand:

Description

Suitable for 6 mm/7 mm (1/4″) chain and 12 mm (1/2″) nylon rope. The combined stainless steel and chromed bronze RC6 automatic rope/chain anchor winch is Maxwell’s smallest version of the vertical RC Series Windlass Range.

Rope (mm) 12
Rope/chain Rope/chain
Drum No
Motor (W) 500
Weight (kg) 8.5
Maximum pull/lift (kg) 350
Chain short link (mm) 6 – 7
Static Hold 700kg
Vertical/Horizontal Vertical
Voltage (V) 12

Owner’s Manual
