Description
| Diameter | Pitch | Width | Weight per meter | Deformation limit | Breaking load | |||
| mm | mm | mm | Kg/mt | kN | kN | |||
| 3 | 0.20 | 16.0 | 0.80 | 5.4 | 12.60 | 0.165 | 0.3 | 2.80 |
| 4,0 | 0,20 | 19,0 | 2,00 | 7,0 | 17,0 | 0,295 | 0,55 | 5,00 |
| 5 | 0.25 | 21.0 | 2.00 | 8.0 | 21.00 | 0.500 | 1.10 | 7.75 |
| 6,0 | 0,30 | 24,0 | 1,20 | 10,0 | 25,2 | 0,730 | 2,50 | 11,50 |
| 8,0 | 0,40 | 32,0 | 1,60 | 14,0 | 33,6 | 1,300 | 4,00 | 20,00 |
